| Display |
|
Network camera |
| Inputs |
Max. 8CH |
| Resolution |
32MP ~ CIF |
| Protocols |
SUNAPI, ONVIF |
|
Decoding |
| Local Display |
FHD : HDMI & VGA Dual monitor
UHD : HDMI Single monitor |
| Multi Screen Display |
[Local Monitor]
- Dynamic layout, Virtual channel view
- Clone mode : Up to 16 Division
- Expand mode : Up to 9 Division
[Web] 1/ 2H/ 2V/ 3V/ 4/ 6/ 8/ 9 |
| Resolution |
[Local Monitior]
FHD Clone mode : 32M(15fps, H.265 Only), 12M(30fps, H.265 Only), 8.3M(50fps), 1080p(240fps), D1(480fps)
UHD Single mode : 32M(15fps, H.265 Only), 12M(30fps, H.265 Only), 8.3M(50fps), 1080p(240fps), D1(270fps)
FHD Expand mode: 32M(12fps, H.265 Only), 12M(25fps, H.265 Only), 8.3M(30fps), 1080p(90fps), D1(200fps) |
| Performance |
|
Operating System |
| Embedded |
Linux |
|
Record |
| Compression |
H.265, H.264, MJPEG |
| Recording Bandwidth |
Max. 120Mbps |
| Resolution |
32MP ~ CIF |
| Mode |
Normal, Dual Stream, Schedule(Continuous/Event), Event (Pre/Post), Bookmark |
| Event Trigger |
Alarm Input, Video Loss, Camera Event(Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event, User Event |
| Event Action |
e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out, FTP,
SUNAPI Command, Shotdown |
|
Search & Play |
| Playback Bandwidth |
Max. 32Mbps |
| User |
Max. 4 Users (Local 1, Remote 3) |
| Simultaneous playback |
Max. 32CH(Local 8CH, Remote 8CH per user) |
| Fisheye Dewarping |
CMS |
| Mode |
Date & Time(Calendar), Event list, Text Search, Smart Search |
| Resolution |
CIF ~ 32MP (Up to H.264 8.3MP, H.265 32MP) |
| Playback Control |
Fast/Slow Forward / Backward, Move one step Up / Down |
|
Storage |
| Supported HDD |
Up to 6TB |
| HDD Slot |
SATA 2ea(Max. 12TB) |
|
Backup |
| File backup |
BU/Exe/AVI(GUI), JPG/AVI(Network) |
| Function |
Multi channel(Up to 8CH) Play, Date-Time/Title display |
| Network |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client) |
| DDNS |
Hanwha DDNS |
| Transmission Bandwidth |
Max. 120Mbps |
|
Audio |
| Input/Output |
8 CH(network) |
| Compression |
G.711, G.726, AAC(16/48KHz) |
| Audio Communication |
2-Way |
| Max Remote Users |
Search(3), Live Unicast(10), Multicast(20) |
| Security |
IP address filtering, User access Log, 802.1x, Encryption
Device certificate(Hanwha Techwin Root CA), Signed firmware |
|
Web viewer |
| Supported OS |
Windows 10, macOS 10.13 |
| Supported browser |
Google Chrome, Microsoft Edge, Mac Safari |
| Viewer Software |
WAVE, SSM, Webviewer, Smart Viewer, Wisenet mobile
Support CGI(SUNAPI) for integration to 3'rd party VMS |
| Functions |
|
Camera Setup |
| Register |
Auto, Manual |
| Item |
IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup (4, 8 point polygon)
Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage |
|
PTZ |
| Control |
Via GUI, Webviewer, SPC-2000 |
| Preset |
300 Presets |
|
Smart phone |
| Support Model |
iOS, Android |
| Protocol Support |
RTP, RTSP, HTTP, CGI(SUNAPI) |
| Control |
Live 8CH(Multi-Profile Support), Playback 4CH |
| Max. Remote Users |
Search(3), Live Unicast(10) |
|
Redundancy |
| Failover |
N+1 |
| ARB |
Support |
| Easy configuration |
P2P(QR code) |
| Interface |
|
Front |
| Indicator |
HDD, Alarm, Power, Record, Backup, Network |
| Storage |
OK |
| HDMI |
1EA 3840x2160 30Hz |
| VGA |
1EA 1920x1080 60Hz |
| Audio |
Out 1EA (3.5mm Audio Jack) |
| Ethernet |
PoE+ RJ-45 8EA (LAN, 10/100), RJ-45 2ea (LAN/WAN 1Gbps) |
| Alarm |
In 4EA, Out 2EA |
| USB |
3EA(Front 2 x USB 2.0, Rear 1 x USB 3.0) |
| Power inlet |
AC 1EA |
| System |
|
Log |
| Log List |
Max. 100,000 (System Log, Event Log each) |
| System Control |
Mouse, Keyboard, Web, Controller (SPC-2000) |
| Language |
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese |
| Environmental |
| Operating Temperature |
0°C to +40°C(32℉ to 104℉) |
| Operating Humidity |
20% ~ 85% RH |
| Electrical |
| Power Input |
100 ~ 240 VAC ±10%; 50/60 Hz |
| Power Consumption |
Max 160W |
| PoE Budget |
100W |
| Mechanical |
| Color / Material |
Black / Metal |
| Dimension (WxHxD) |
370 x 50.7 x 324.3 mm (14.57 x 2 x 12.77 inch) |
| Weight |
2.7Kg (5.95lb) |
| Intelligent Analysis |
|
AI Search |
| Object Attribute |
Compatible for Wisenet AI Camera |
