| Video |
| Imaging Device |
1/2" CMOS |
| Resolution |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
| Max. Framerate |
H.265/H.264: Max. 60/50fps(60Hz/50Hz, AI analytics on), Max. 120/100fps(60Hz/50Hz, AI analytics off)
MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| Min. Illumination |
Couleur: 0.007Lux(F1.3, 1/30sec, 30IRE) B/W : 0.0007Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on), 30/25fps
Couleur: 0.014Lux(F1.3, 1/60sec, 30IRE) B/W : 0.0014Lux(F1.3, 1/60sec, 30IRE), 0Lux(IR LED on), 60/50fps
Couleur: 0.028Lux(F1.3, 1/120sec,30IRE) B/W : 0.0028Lux(F1.3, 1/120sec, 30IRE), 0Lux(IR LED on), 120/100fps |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
4.38~9.33mm(2.13x) Vari-focale motorisée |
| Max. Aperture Ratio |
F1.3(Wide)~F2.15(Tele) |
| Angular Field of View |
H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple focus |
| Lens Type |
P iris |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0˚~360˚ / -45˚~85˚ / 0˚~355˚ |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
WiseNR Ⅱ(using AI engine)
SSNRⅤ |
| Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
| Motion Detection |
8ea, polygonal zones |
| Privacy Masking |
6ea, rectangle zones
- Couleur: Gray/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Fonction de contrôle Auto prefer shutter basée IA engine |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Classification d'objets: Detéction (Personnes/Visages/Véhicules/Plaques d'immatriculation
Attributes: Person(Gender, Couleur and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type: car/bus/truck/motorcycle/bicycle and Couleur)
Support BestShot per object
Analyses d'événements basée AI
- Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit), Détection de masques, distancement social, Slip&Fall detection
Analytics events
- Defocus detection, Détection de mouvement, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear)
Support WiseDetector for Adding custom objects
*Some of the video analytics only works with people and vehicle detection |
| Business Intelligence |
People/Vehicle/Crowd counting, Gestion de queue, Heatmap based on AI engine |
| Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
| Alarm Events |
When alarm trigger occurred
- File upload(image): e-mail/FTP
- Notification: e-mail
- Recording: SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover: PTZ preset, send message by HTTP/HTTPS/TCP
- Audio clip playback
- MQTT: publication |
| Audio In |
Selectable(mic in/line in/Built in mic) |
| Audio Out |
Line out |
| Light Type |
IR LED (850nm) |
| IR Viewable Length |
WiseIR 40m(131.23ft) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Streaming multiple(jusqu'à 6 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), MQTT |
| Application Programming Interface |
ONVIF Profile S/G/T/M
SUNAPI(HTTP API)
Wisenet open platform
- WiseAI application included(Analytic based on AI, Business intelligence) |
| Security |
| OS / Firmware Protect |
Encrypted Firmware, Secure boot, Signed Firmware |
| User authentication |
Digest Authenticaton, Prevent brute-force attack |
| Network authentication |
IEEE 802.1X (EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication |
HTTPS, WSS (WebSocket Secure) |
| Access Control |
IP-based access control |
| Data Protect |
Encryption Credentials, Encrypt compress for live recording file |
| Audit |
Access / System / Event Log management |
| Device ID |
Device certificate (Hanwha Techwin Root CA) |
| Secure Storage |
TPM, SDcard partition encrypt |
| Security Certificate |
TPM with FIPS 140-2 level 2 |
| General |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese,
Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 2slots 512GB |
| Memory |
4096MB RAM, 512MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-25°C ~ +50°C (-13°F ~ +122°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP52, IK10 |
| Input Voltage |
PoE+(IEEE802.3at), 12VDC |
| Power Consumption |
PoE+: Max 19.50W, typical 16.00W
12VDC: Max 17.00W, typical 13.50W |
| Mechanical |
| Couleur / Material |
White / Aluminum, Coupole de dôme à revêtment dur renforcés |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
Ø160x125mm(6.30x4.92"), Weight : 1.60Kg (3.53lb) |
| Compatible Conduit hole / Gangbox |
1/2"(M20)
Single, Double, 4"Octagon, Square |
| Hanging Mount (Dome) |
SBP-167HMW |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 30.0m(98.43ft) / Tele: 95.0m(311.82ft) |
| Observe (63PPM/ 19PPF) |
Wide: 12.0m(39.37ft) / Tele: 38.0m(124.73ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 6.0m(19.69ft) / Tele: 19.0m(62.36ft) |
| Identify (250PPM/ 76PPF) |
Wide: 3.0m(9.84ft) / Tele: 9.5m(31.18ft) |
