| Video |
| Imaging Device |
1/2.8" CMOS x 4CH |
| Resolution |
2592x1520, 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(@4MP Max. 5fps) |
| Min. Illumination |
Couleur: 0.075Lux(F1.5, 1/30sec, 30IRE)
BW: 0.0075Lux(F1.5, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.3~5.7mm(1.7x) Vari-focale motorisée |
| Max. Aperture Ratio |
F1.5(Wide)~F1.9(Tele) |
| Angular Field of View |
H: 100°(Wide)~53°(Tele)
V: 54°(Wide)~30°(Tele)
D: 125°(Wide)~61°(Tele) |
| Min. Object Distance |
1.3m(4.27ft) |
| Focus Control |
Simple focus |
| Lens Type |
Fixed iris |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~360° / 0°~65° / 0°~90° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ, WiseNRⅡ(Basée sur machines IA) |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
6ea, rectangular zones
- Couleur: Grey/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker(2~1/12,000sec)
Prefer shutter control(Basée sur machines IA) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) - Each channel separately |
| Analytics |
Classification d'objets: Detéction (Personnes/Visages/Véhicules/Plaques d'immatriculation
Attributes: Vehicle(Type: car/bus/truck/motorcycle/bicycle)
Support BestShot
Analyses d'événements basée AI
- Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Détection de mouvement, Tampering, Audio detection, Classification accoustique, secteurs virtuels (entrées/Sorties) |
| Alarm I/O |
2 configurable I/O ports
* Support extra alarm I/O via optional SPM-4210 I/O box |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule, MQTT subscription |
| Alarm Events |
When alarm trigger occurred
- File upload(image): e-mail/FTP
- Notification: e-mail
- Recording: SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover: PTZ preset, send message by HTTP/HTTPS/TCP
- Audio clip playback
- MQTT: publication |
| Audio In |
Selectable(mic in/line in) |
| Audio Out |
Line out |
| IR Viewable Length |
WiseIR 15m(49.21ft) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100/1000BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Basée sur machines IA) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(10 users) / Multicast
Streaming multiple(jusqu'à 3 profiles per channel) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast), MQTT |
| Application Programming Interface |
ONVIF Profile S/T
SUNAPI(HTTP API)
Wisenet open platform |
| Security |
| OS / Firmware Protect |
Secure boot, Signed firmware, Firmware encryption |
| User authentication |
Digest Authentication |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP |
| Access Control |
IP address filtering |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log |
| Device ID |
Device Certificate(Hanwha Private Root CA) |
| Secure Storage |
TPM(Trusted platform module) |
| Security Certificate |
TPM with FIPS 140-2 level 2 |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot Max. 1TB(512GBx2) |
| Memory |
8GB RAM, 1GB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F)
* Start up should be done at above -35°C
0~95% RH(non-condensing)
Humidity control /w Air vent |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~90% RH |
| Certification |
IP66, NEMA4X, IK10 |
| Input Voltage |
PoE+(IEEE802.3at Type2, Class4) |
| Power Consumption |
PoE+: Max 25.5W, typical 22.0W |
| Mechanical |
| Couleur / Material |
Body: White / Aluminum
Bubble: Hard-coated dome |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø250x114.2mm(ø9.84x4.50"), 2730g(6.02 lb) |
| Compatible Conduit hole / Gangbox |
Conduit hole: 19.1mm(3/4")(M25)
Gangbox: Single, Double, 4" Octagon, Square |
| Hanging Mount (Dome) |
SBP-250HMW, SBP-276HMW |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A
KS C 9832 Class A , KS C 9835 |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66, IEC/EN 62262 IK10
NEMA 250 type 4X |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 43.5m(142.71ft) / Tele: 104.0m(341.13ft) |
| Observe (63PPM/ 19PPF) |
Wide: 17.4m(57.09ft) / Tele: 41.6m(136.45ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 8.7m(28.54ft) / Tele: 20.8m(68.23ft) |
| Identify (250PPM/ 76PPF) |
Wide: 4.3m(14.27ft) / Tele: 10.4m(34.11ft) |
